I'm currently learning more about hydraulics, this has required me to build some new assemblies in Solidworks, these will be added to the main Solidworks sections soon but thought I would post some of my in progress shots that where used on my Instagram account, plus some finished renders, more will be added soon!

Hydraulic pump assembly I created - playing around with gears - little animation!

Some in progress Instagram stories!

Some initial renders - exploring ideas in Keyshot

Finished hydraulic cylinder renders - still not happy but progress made and was fun making these

I will be adding the high res images soon along with the engineering layout documents for these, we also have some simulations planned using the hydraulic pump.
